Component Cleaning Machine

Input Shafts Washing Machine

The Input Shafts Washing Machine is meticulously designed to offer efficient and rapid cleaning suitable for parts with straightforward geometries. This adaptable system accommodates both batches of small parts loaded onto baskets and individual larger parts secured on fixtures.

The machine configuration adopts the Rotary Table Spray Washers approach. Components are positioned onto a rotary basket, which is set in motion by a motor and gearbox assembly operating at a controlled slow speed. During rotation, a solution comprising water infused with alkaline is propelled from the tank using a High Pressure pump. This solution is directed through inline filters and multiple spray nozzles strategically located above, below, and around the rotary table within the top-loading spray washer. This arrangement ensures a comprehensive and thorough cleaning process, delivering superior results.

Subsequent to the cleaning phase, the solution from the wash chamber of the Rotary Table Washer drains back into the tank via a basket filter. To ensure optimal performance, a spray pressure indicator equipped with a Glycerine-filled pressure gauge monitors the line pressure. Additionally, the control panel is furnished with indicators for low water levels and a digital temperature indicator cum controller, facilitating ease of operation and precise monitoring of the washing process.

The Input Shafts Washing Machine exemplifies an integrated and effective solution for cleaning components, fostering efficiency, quality, and consistent manufacturing processes.

Working Temperature: 50 to 65 deg.
High Pressure Alkaline sprays wash.
After Spray wash Rinse.
Compressed air blowing.
Hot air blowing.
Timers are provided for controlling wash cycle and drain time duration..

High pressure vertical / horizontal pumps.
Hot Air centrifugal blower with Air heater for component drying.
Stainless Steel V-Jet Nozzles ~ Durability and precise 360 degree cleaning coverage
PLC Controlled Panel with HMI Display
Gravity Filter to keeps tanks free of larger debris
Mist collector for Exhaust systems.
Oil Skimmer for effective removal of oil from tank.
Rotary type component cleaning machines wash tank can be also provided with Oil separator for effective removal of oil from the tank in high volume.
Washable Filtration system for reuse of aqueous solution.
A thermostat-controlled electric immersion heater in Rotary Basket Cleaning Machine maintains the aqueous cleaning solution at the desired temperature.
Rinse tank for removing alkalinity from component post spray wash
